TOP 600 XTPRO: Service & Maintenance Manual - rev. 2.0
XC-1: Output ports cable
CPU board – RJ45-RS232 board
CPU board
CN2
Signal Color RJ45-RS232
board
CN4
1 +12 Vdc flat 1
2 +12 Vdc flat 2
3 Tx to TGS flat 3
4 +5 Vdc flat 4
5 Rx from TGS flat 5
6 Tx to PC flat 6
7 Ground flat 7
8 Rx from PC flat 8
9 Ground flat 9
10 Ground flat 10
CR-XT: Non coded heart rate meter cable
CPU board – Cardio receiver
CPU board
CN4
Signal Color Receiver
1 +5 Vdc Red 1
2 Pulse per beat Blue 2
6 Ground Black 3
The above description of cables does not detail the ground node connections.
Page 2.5
