WG3100-Series GSM VoIP Gateway User Manual
_______________________________________________________________________________
Techroutes Network Pvt. Ltd.
95
Getting start to RTP capture
PCM capture is help to analysis voice stream between gateway and remote IPPBX/SIP Server.
To enable RTP capture:
Select RTP special on Network Capture page
Click Start to enable RTP capture
Dialing out through gateway, start talking a short while then hangup the call.
Click Stop to disable RTP capture
Save the capture to local computer
The capture is named to ‘capture(x).pcap’, x is serial number of capture and will be added 1 in next time. The sample of RTP
capture as below:
Getting start to DSP capture
DSP capture is help to analysis voice stream inside DSP chipset. The DSP chipset will handle RTP from IP network as well as
voice stream from GSM/CDMA modular.
To enable DSP capture:
Select DSP only on Network Capture page
