TP8-64 - User Manual Signaling
2-9
2.3.3 PROGRAM STATUS LED - YELLOW
The program status LED signal the status of the first 6 programs (1...6) as follows:
z LED blinking quickly = the pre-arming phase is active.
The pre-arming phase permits arming/disarming of other
programs. Then, the volontary exclusion of zones from
the detection of alarms is possible.
z LED blinking slowly = the program is partset
The zones included in the by-pass program are
temporarily disabled from the detection of alarms.
z LED on = the program is armed
z LED off = the program is in stand-by
Arming and disarming as well as the activation and deactivation of by-pass are logged in
the event buffer of the control panel.
2.3.4 ZONE STATUS LED - YELLOW
The zone status LED signals zone status during arming:
z LED blinking = one of the zones is open
z LED off = none of the zones is open
2.3.5 KEY LED - GREEN
The key LED signals:
z LED on = the key has been recognized
z LED off = no key has been inserted
z LED blinking = a key has been inserted into another keypoint or, if
contemporaneously the red general alarm LED is lit,
an unknown key has been inserted
WARNING
If a general alarm is active, arming by key is denied.
