TP8-64 - User Manual Control by keypoint
5-13
5.5 TX240-3 WIRELESS KEY
If the control panel is equipped with a wireless receiver-transmitter, it is possible to control the system by wireless key.
The wireless RTX200/433868 receiver-transmitter or RX110 receiver accepts up to 32 wireless keys type TX240-3.
According to programming, the wireless key permits the arming/disarming programs (from 1 to 8) and
activation/deactivation of remote control (from 1 to 8) through 3 individually programmable function keys.
5.5.1 ARMING
The control panel can be armed through the programs (1 to 8). If the system is equipped with a wireless
receiver-transmitter, it is possible to arm and disarm as well parset the programs by a wireless key programmed
accordingly. The programs groupe the zones (1 to 64) that are actived, i.e. are enabled for the detection of alarms,
simultaneously upon arming of the program. The wireless key permits to arm only one program at a time (single
arming). The wireless key permits arming with exclusion of open zones if it is programmed accordingly.
The wireless key used behaves according to its configuration:
z Access periods (1 to 8)
z Association of the function keys
• Disarming (all the programs that have been armed previously by the wireless key)
• Arming program (1 to 8)
• Disarming program (1 to 8)
• Activation deactivation remote control (1 to 8)
• Activation remote control (1 to 8)
• Deactivation remote control (1 to 8)
z Attributes:
• By-pass
• Confirmation of disarming (hold-up block)
• Automatic abort of the telephone channels on disarming
• By-pass of general alarms
• Hold-up
• Zone exclusion disabled
VERIFICATION OF PROGRAM STATUS
The wireless keys do not permit viewing of system status.
5.5.1.1 SINGLE ARMING
To arm a program, simply press the corresponding function key.
Example (function key 2 associated to arming of program 1)
Press the function key 2.
On the console the LED corresponding to the program 1 starts blinking slowly (1 flash per second) and continues
blinking for 10 seconds (zone exclusion time).
During this period of time, it is possible to exclude possible open zones if the wireless key has been programmed
accordingly.
The buzzer of the console is activated for approx. 2 seconds.
The chime output of the output expansion module ESP32-OCN (if present) is activated for approx. 2 seconds.
After 10 seconds, the program selected is armed.
5.5.2 DISARMING
To disarm the control panel, it is necessary that one function key of the wireless key used is programmed for disarming
of the program previously armed or for disarming of all the programs associated to the wireless key.
If so, press the corresponding key.
Example (function key 3 associated to total disarming)
Press the function key 3
On the console the LED corresponding to the programs previously armed by this wireless key are switched off.
The buzzer of the console is activated for approx. 2 seconds
The programs previously armed by this wireless key, are disarmed.
WARNING
The wireless key does not possess any LED for system status viewing. This means that for checking of
system status and for verifying the execution of the arming/disarming command, the user has to
approach a console.
WARNING
The disarming function permits disarming of the programs associated to the wireless key only.
