Tecnoalarm TP8-64 - Arming with Master Code

Control by console User Manual - TP8-64
4-6
4.1.1 ARMING WITH MASTER CODE
Enter the master code (default code 12345), e.g.:
+ 12345
During the 10 seconds to come, it is possible to select the programs to be armed/
disarmed (pressing the program number the first time the program is selected, pressing
it the second time it is deselected).
On every keystroke the counter is reset.
Select the programs to be armed, e.g.:
+ 12
Once the programs have been selected, for 10 seconds, on the display is viewed
Arming followed by the number/name of the programs selected.
The yellow LED corresponding to the programs selected start blinking.
ZONE EXCLUSION TIME
For 10 seconds after selecting the programs, it is possible to exclude manually some of
the zones from the detection of alarms with a procedure explained lateron.
If you do not wish to exclude any zone, it is possible to confirm the selection without
awaiting the expiry of the zone exclusion time by pressing # (hash):
+ #
EXIT TIME
The zones defined as delayed, upon arming observe the exit time programmed by the
installer. If the programs selected contain delayed zones, on expiry of the zone
exclusion time follows the exit time and the programs in question are only armed on
expiry of the exit time. Once the exit time has expired, the yellow program LED become
lit and remain lit until disarming of these programs.
On condition that there are no open zones and arming has been completed correctly, on
the display is viewed Arming ctrl panel OK.
If the programs selected do not contain delayed zones, on expiry (or abort) of the zone
exclusion time, the programs in question are armed and the corresponding yellow LED
become lit immediately.
4.1.1.1 EXCLUSION OF OPEN ZONES
After selecting the programs to be armed, during the 10-seconds zone exclusion time, if
there are open zones (direct or delayed type 2), these are viewed in sequence on the
display.
A zone may result open for instance in case of fault of the detector connected.
To arm the programs selected excluding the open zones, press:
+ #YES
The zones remain excluded until disarming of the program. They are activated
automatically again the next time the program is armed.
4.1.1.2 VOLUNTARY ZONE EXCLUSION
After selecting the programs to be armed, during the 10-seconds zone exclusion time, it
is possible to exclude some of the zones volontarily from the detection of alarms.
Select the zones to be excluded pressing:
+ yw to select the zones to be excluded
On the display are viewed in sequence all the zones included in the programs selected.
Exclude the zone selected pressing:
+ #YES to exclude the zone selected
Select another zone to be excluded with the keys arrow up and arrow down or exclude
sequential zones pressing repeatedly # (hash).
- ACCESS -
Master
Arming
Program x
OPEN ZONES
Zone xxx
Arming
Excl. with MENU
EXCLUDE with #
Zone xxx
WARNING
To abort arming of the programs selected press the EXIT key. The process is aborted and the control
panel returns to stand-by.
ZONES EXCLUDED
Arming
Ctrl panel OK
WARNING
If the open zones are not excluded, on expiry of the zone exclusion time (and perhaps the exit time) the
programs are armed and the open zones are activated. Consequently the alarme is released.
