FieldPilot Setup
Icon Description Factory
Setting
Range
Autosteer. On
Valve Frequency. 175 1 - 5000
Minimum Duty Cycle Left. 0.0 0.0 - 50.0
Minimum Duty Cycle
Right.
0.0 0.0 - 50.0
Maximum Duty Cycle. 100 25 - 100
Coarse Steering
Adjustment.
25.0 1.0-100.0
Fine Steering Adjustment. 25.0 1.0-100.0
Deadband. 1 1-10
Lookahead. 4.0 0.0-10.0
APPENDIX D UNIT SPECIFICATIONS
Dimensions Matrix 570G 6.36 in. x 5.87 in. x 2.3 in.
161.5 mm x 149.1 mm x 58.4 mm
Matrix 840G 10.6 x 7.1 x 2.4 in.
27.0 x 18.0 x 6.0 cm
Weight Matrix 570G 1.75 lbs..
0.794 kg
Matrix 840G 2.35 lbs.
1.06 kg
Connector PWR/CAN 8 pin Conxall
Camera 5 pin Conxall
Speed/Status 4 or 8 pin Conxall
Environmental Storage -10 to +70°C
Operating 0 to +50°C
Humidity 90% non-condensing
Display Matrix 570G 320 x 240 resolution
5.7 in.
14.5 cm
Matrix 840G 800 x 600 resolution
8.4 in.
21.3 cm
Input/Output USB 2.0
Power Requirement < 9 watts @ 12 VDC
