Calibration constants, 4-29
CH
1
SELECT, 4-3
CH 2 SELECT, 4-3
CHI and CH2 Self Cal, 4-28
CHlOFF and CH20FF, 6-5
Channel isolation, 8-5
CLEAR button,
3-9,4-2
Clearing
menus, 4-3
saved waveforms, 4-3
COMM PORT connector, 3-20
CONFG, 3-18,4-23,4-24
CONT ENV acquisition, 3-17,
4-20,6-6,6-14
Common-mode noise, 5-6
Common-mode potential, 8-5
Common-mode rejection ratio,
8-5
Common-to-ground capaci-
tance, 8-4
Construction, 8- 12
Controls and Connectors, 3- 1,
3-8
reference tables, 3-1 -3-5
Cooling, 8-12
CRT,
3-8,8-12
graticule dimensions, 1-4
Current required, when charging
batteries, 8-9
Data points, 6-9
DC accuracy, 1-2,8-2
DC Balance, 8-3
DC Coupling, 6-5
Deflection factor, 8- 1
Differential Measurements, 5-6
Dimensions, 1-3
height, 8-12
length, 8-12
width, 8-12
Display alignment pattern, 4-25
Display MODE menu, 4-21
Display Mode
button, 3-18
menu, 4-21
Display update, 6-5
ENV acquisition, 3-17, 4-20, 5-9,
6-13
Environmental Specifications,
8-10
requirements, 8- 10
Equivalent-Time Storage, 6-9
Erasing Front Panel Setups, 4-17
ERASE ALL, 4- 18
EXT
TRIG INPUT
connector, 3-20
self calibration, 4-28
Ext Trigger
coupling, 6-12
source, 6-12
External battery charger, 6-15
External Power connector, 3-20
External Power input current, 8-9
External Supply Voltage
ac, 1-4
dc, 1-4
external power indicator, 2-3
ranges, 3-20,2-1,8-8
Features, summary of, 1
-
1
Finish, 8-12
Firmware Version, 4-30
Floating Measurements, 5-6
Focus control, 3- 19
Front-panel setups
recall, 4-16
save, 4-14
INDEX-2
REV JUN 1989
