GND Coupling, 6-5
Graticule Measurements, 5- 1
Horiz alignment, 3- 19, 4-26
Horizontal
display accuracy, 1-2
SECIDIV range, 8-6
Horizontal Controls, 3-1 2
Horizontal POSITION control,
3-12,4-8
range, 8-7
Horizontal POSITIONING, 4-8
Horizontal System
displayed accuracy, 8-7
sample rate, 8-7
specifications, 8-6
Humidity, operating and
nonoperating, 8- 11
IDENT,
3-18,4-30
INIT button, 3-9, 4-2
INVERT Balance, 8-3
Input Coupling, 3-1 1, 4-4, 6-5
lnput current, 8-4
lnput linear range, 8-3
Intensity control, 3-20
Introduction, 7-1
Invert Display MODE, 4-6
L
Lead-acid cells, 6-15
LEVEL, 4-9,6-13
M
Magnification, 4-8
Maximum applied voltage on
RS-232 interface, 8-8
Maximum common-mode volt-
age, 1-3
Maximum normal-mode voltage,
1-3
Maximum potential between
channels, 1-3
Maximum potential between
power and common, 1-3
Maximum power consumption,
8-9
Maximum rated common-mode
potential, 8-5
Maximum rated input voltage,
8-4
Maximum rated potential between
channels, 8-5
Measurements
differential, 5-6
floating, 5-6
rise time, 5-5
time, 5-4
using the graticule markings,
5- 1
voltage, 5-2
Menu Selections, 4-2
Menu-select buttons,
3-9,4-2
MID Trigger, 4-19, 6-12
MODE
acquisition, 6-6
display, 6-5
trigger, 4-10
NONSTORE Mode, 4-3,6-5
NORM, 4-9,4-10
acquisition, 6-13
trigger mode, 6-10
NORM acquisition, 3-17, 4-20
sample rate, 8-7
Nonvolatile memory, 6-15
REV JUN 1989
INDEX-3
