Brief Procedures (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Acquisition ta
b in the control window that displays. Click each of the
acquisition m odes and c onfirm that the following statements are true.
Sample mode di
splays an actively acquiring waveform on-screen. (Note
that there is a small amount of noise present on the square wave).
Peak Detect
mode displays an actively acquiring waveform on-screen with
the noise present in Sample mode "peak dete cted".
HiResmoded
isplays an actively acquiring waveform on-screen with the
noise that was present in Sample mode reduced.
Average mo
de displays an actively acquiring waveform on-screen with
the noise reduced.
Envelope
mode displays an actively acquiring wa veform on-screen with
the noise displayed.
NOTE. Default setup enables e nhanced triggering. Enhanced triggering can
cause a slower acquisition rate that can be noticed in waveform database mode.
As waveform database mode acquires 100,000 samples, the display intensity
will increase, be cleared, and then the process will start over. When enhanced
trigg
ering is turned off, and with the specified settings and input signal, the
display reaches full intensity right away.
Wave
form Database mode displays an actively acquiring waveform
on-screen with the noise displa yed.
8. Tes
t all channels: Repeat steps 2 through 7 until all four input channels are
verified.
9. Re
move the test hookup: Disconnect the equipment from the instrument.
Verify the Time Base
Equipment required Prerequisites
< 4 GHz models: One precision 50 Ω coaxial
cable (Item 4)
< 4 GHz models: One BNC to Minigrabber
adapter (item 18)
≥ 4 GHz models: One SMA cable (item 21)
≥ 4 GHz models: One adapter (item 19)
None
1. Initialize the instrument: Push the front-panel Default Setup button.
2. Hook up the s ignal source: Connect the probe compensation or fast edge
output to the Ch 1 input as shown in the following figure.
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 3–9
