Tektronix DPO7000 Series Technical Reference

Specifications (MSO/DPO5000 Series)
Table 2-2: Hori
zontal and acquisition system specifications
Characteristic Description
Instrument Maximum sampl
erate
Number of
channels
10 GS/s
1or2
MSO5204, DPO5204,
MSO5104, DP
O5104
5GS/s
3or4
Sample rate
MSO5054, DPO5054,
MSO5034, D
PO5034
5GS/s
1–4
Record length
Analog cha
nnels
Option Number of
Channels
2GHz 1GHz
500 MHz 350 MHz
3 or 4 12.5 M 12.5 M 12.5 M 12.5 M
Standard
1 or 2 25 M 25 M 12.5 M 12.5 M
3or4 25M 25M 25M 25M
Option 2RL
1or2 50M 50M 25M 25M
3or4 50M 50M 50M 50M
Option
5RL
1 or 2 125 M 125 M 50 M 50 M
3 or 4 125 M 125 M 125 M 125 M
Option 10RL
1 or 2 250 M 250 M 125 M 125 M
Record Length
Digital channels
The record length ranges for a standard instrument are the same as for the analog channel
spec
ification table (above).
The record length ranges for an instrument with an option are the same as for the analog
channel specifications, up to 40M.
Record length
1 K 10 K >10
K
Seconds/Division range
200 ps – 40 s 200 ps – 400 s 200 ps – 1.00 k s
Maximum update rate
Maximum triggered acquisition rate: >250,000 wfm/s
Aperture Uncertainty
≤(3 ps + 0.1 ppm × record duration)
RMS
, for records having ≤1 minute duration
Long-term sample rate and
delay time accuracy
±5 ppm over any ≥1mstimeinterval
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 2–9

Tektronix DPO7000 Series Specifications

General

Brand	Tektronix
Model	DPO7000 Series
Category	Test Equipment
Language	English
