Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-2: Hori
zontal and acquisition system specifications, all M SO70000/C, DSA/DPO70000B/C, and DPO7000
Series models
Characteristic Description
Sample rate, maximum
Real-time sample rate range
Number of channels acquired
(Standard) (Option 2SR)
MSO70804, MSO70604,
MSO70404,
DSA70804B, DSA70604B,
DSA70404B,
DPO70804B, DPO70604B,
DPO70404B
All channels
Up to 25 GS/s
All channels
Up to 50 GS/s
MSO72004C, MSO 71604C,
MSO71254C, DSA72004C,
DSA71604C, DSA71254C,
DPO72004C, DPO71604C,
DPO71254C
Two channels
Up to 100 GS/s
1
40 GS/s
DPO7354 and DPO7254
2
20 GS/s
3or4
10 GS/s
1
20 GS/s
DPO7104
2
10 GS/s
3or4
5GS/s
1
10 GS/s 20 GS/s
DPO7054
2
5GS/s 10GS/s
3or4
2.5 GS/s 5 GS /s
Equivalent-time s ample rate or
interpolated waveform rate range
Equivalent-time acquisition can be enabled or disabled. When disabled, waveforms are
interpolated at the fastest time base settings.
≥ 4 GHz models Up to 5 TS/s and 0.2 ps trigger placement resolution
< 4 GHz models Up to 4 TS/s
The maximum record length depends on the installed record length options. Maximum record
length is less in serial trigger mode, hi-res mode, or when using the FIR filter.
Standard o n MSO70000/C Series,
DSA70000B/C Series, and DPO70000B/C
Series
12,500,000 points
Option 2XL installed, standard on
DSA70000/B Series
31,250,000 points
Option 5XL installed 62,500,000 points (all channels)
Option 10XL installed 125,000,000 points (all channels)
Maximum record length, sample
mode,
≥ 4 GHz models
Option 20XL installed 250,000,000 points (all channels)
1–34 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
