Tektronix DPO7000 Series Technical Reference

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-2: Horizontal and acquisition system specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000
Series models
(cont.)
Characteri
stic
Descriptio
n
Maximum record length, sample
mode, < 4 GHz
models
The maximum
record length depends on the number of active channels and the record length
options installed. Maximum record length is less in serial trigger mode, hi-res mode or when
using the FIR filter.
Standard, DPO7354 and
DPO7254
10 GS/s
20 GS/s or
less
40 GS/s or less
12,500,000 points (3 or 4 channels)
25,000,0
00 points (2 channels)
50,000,000 points (1 c hannel)
DPO7104 5 GS/s
10 GS/s or less
20 GS/s o
rless
12,500,000 points (3 or 4 channels)
25,000,000 points (2 channels)
50,000,
000 points (1 c hannel)
DPO7054 2.5 GS/s
5 GS/s or less
10 GS/s or less
12,500,
000 points (3 or 4 channels)
25,000,000 points (2 channels)
50,000,000 points (1 c hannel)
Option 2RL installed,
DPO73
54 and DPO7254
10 GS/s
20 GS/
sorless
40 GS/s or less
25,000,000 points (3 or 4 channels)
50,00
0,000 points (2 channels only)
125,000,000 points (1 channel only)
DPO7104 5 GS/s
10 GS/s or less
20 GS
/s or less
25,000,000 points (3 or 4 channels)
50,000,000 points (2 channels only)
125,
000,000 points (1 channel only)
DPO7
054
2.5 G
S/s
5 GS/s or less
10 GS/s or less
25,0
00,000 points (3 or 4 channels)
50,000,000 points (2 channels only)
125,000,000 points (1 channel only)
Option 5RL installed,
DPO
7354 and DPO7254
10 GS/s
20 G
S/s or less
40 GS/s or less
50,000,000 points (3 or 4 channels)
125
,000,000 points (2 channels only)
250,000,000 points (1 channel only)
DPO7104 5 GS/s
10 GS/s or less
2
0GS/sorless
50,000,000 points (3 or 4 channels)
125,000,000 points (2 channels only)
2
50,000,000 points (1 channel only)
D
PO7054
2
.5 GS/s
5 GS/s or less
10 GS/s or less
5
0,000,000 points (3 or 4 channels)
125,000,000 points (2 channels only)
250,000,000 points (1 channel only)
Option 10RL installed,
DPO7354 and D PO7254
10 GS/s
20 GS/s or less
40 GS/s or less
125,000,000 points (3 or 4 channels)
250,000,000 points (2 channels only)
500,000,000 points (1 channel only)
Maximum record length, HiRes
mode
Half the record length of sample mode
Seconds/division range
≥ 4 G Hz models
Fastest sweep speed is 20 ps per division
< 4 GHz models
Fastest sweep speed is 25 ps per division
Acquisition update rate, typical
≥ 4 G Hz models Fast Acquisition on: 300,000 waveforms per second maximum
< 4 GHz models Fast Acquisition on: 250,000 waveforms per second maximum
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 1–35
