Performance Tests (MSO/DPO5000 Series)
Table 4-3: Maxi
mum bandwidth frequency worksheet
Model: MSO5204, DPO 5204
Impedance Vertical S cale Maxim um bandwidth
10 mV/div — 1 V/div
500 MHz
1
5mV/div
500 MHz
1
2mV/div
350 MHz
50 Ω
1mV/div
175 MHz
5 mV/div — 1 V/div
500 MHz
2mV/div
350 MHz
1MΩ
1mV/div
175 MHz
Model: MSO5104, DPO 5104
Impedance Vertical S cale Maxim um bandwidth
5 mV/div — 1 V/div
500 MHz
1
2mV/div
350 MHz
50 Ω
1mV/div
175 MH
z
5 mV/div — 1 V/div
500 MH
z
2mV/div
350 M
Hz
1MΩ
1mV/div
175
MHz
Model: MSO5054, DPO 5054
5mV/div—1V/div
500
MHz
2 mV/div
350
MHz
50 Ω
1 mV/div
17
5MHz
5mV/div—1V/div
5
00 MHz
2 mV/div
3
50 MHz
1MΩ
1 mV/div
175 MHz
Model: MSO5034, DPO 5034
2 mV/div — 1 V/div
350 MHz
50 Ω
1mV/div
175 MHz
5 mV/div — 1 V/div
350 MHz
2mV/div
350 MHz
1MΩ
1mV/div
175 MHz
1
For DPO5204, MSO5204, DPO5104, and MSO5104 bandwidth performance verification, use 500 MHz on the
10 mV/div and 5 mV/div vertical scale.
14. Use the values of V
bw-pp
and V
in-pp
stored in the test record to calculate the Gain
at bandwidth with the following equation:
Gain = V
bw-pp
/ V
in-pp
To pass the performa n ce measurement test, Gain should be ≥ 0.707. Enter
Gain in the test record.
