Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-3: Trig
ger specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series models
Characteristic Description
Trigger jitter, DC coupled, A edge,
random holdoff, typical
≥ 4 GHz models 100 fs using enhanced trigger placement. 1 ps rms for low frequency, fast rise time signal, A
edge, time h
oldoff = 30 μs
< 4 GHz model
s
1.5 ps rms fo
r low frequency, fast rise time signal
(DPO7104 and DPO7054: 3 ps total trigger jitter.)
Edge trigger sensitivity, DC
coupled, typical
All sources, positive or negative edge, for vertical scale settings ≥10 mV/div and ≤1V/div
Trigger Source Sensitivity
A Event trigger
≤ 4%FS from DC to 50 MHz
≤ 10%FS at 4 GHz
≤ 15%FS at 6 GHz
≤ 20%FS at 8 GHz
≤ 50%FS at 11 GHz
20%FS from DC to 20 GHz (typical, enhanced trigger on, auto
mode only for frequencies above 8 GHz)
B Event trigger
≤ 4%FS from DC to 50 MHz
≤ 10%FS at 4 GHz
≤ 15%FS at 6 GHz
≤ 50%FS at 9 GHz
20%FS from DC to 20 GHz (typical, enhanced trigger on, auto
mode only for frequencies above 6 GHz)
≥ 4 GHz models
Auxiliary input
250 mV from DC to 50 MHz, increasing to 350 mV at 1 GHz
< 4 GHz models Trigger Source Sensitivity
Main and Delayed trigger
≤ 0.7 div from DC to 50 MHz
≤ 1.2 div at 2.5 GHz
≤ 2.5 div at 3.5 G Hz with BWE on
Auxiliary input
1MΩ: 250 mV from DC to 50 MHz, increasing to 350 mV at
250 MHz
50 Ω: 150 mV from DC to 50 MHz, increasing to 200 mV at
1.8 GHz
Video trigger, Ch1 - Ch4 0.6 to 2.5 divisions of video sync tip
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 1–41
