Tektronix DPO7000 Series Technical Reference

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-2: Horizontal and acquisition system specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000
Series models
(cont.)
Characteri
stic
Descriptio
n
MSO70804,
DSA/DPO70804B,
MSO70604,
DSA/DPO70
604B at
25 GS/s, 6 GHz, BWE
on
1.445 ps rms
, 14.45 ps pk-pk, <10 ns pulse width, 10 mV/div, amplitude = 80% FS
1.295 ps rms, 12.95 ps pk-pk, <10 ns pulse width, 50 mV/div, amplitude = 80% FS
1.329 ps rms, 13.29 ps pk-pk, <10 ns pulse width, 100 mV/div, amplitude = 80% FS
MSO70804,
DSA/DPO7
0804B,
MSO70604,
DSA/DPO70604B,
MSO7040
4,
DSA/DPO70404B at
25 GS/s, 4 GHz, BWE
on
1.674 ps rms, 16.74 ps pk-pk, <10 ns pulse width, 10 mV/div, amplitude = 80% FS
1.437 ps r
ms, 14.37 ps pk-pk, <10 ns pulse width, 50 mV/div, amplitude = 80% FS
1.478 ps rms, 14.78 ps pk-pk, <10 ns pulse width, 100 mV/div, amplitude = 80% FS
For sign
als having amplitude greater than 5 divisions, reference level = 50%, filter set to
sin(x)/x, acquired at 10 mV/div or greater. The displayed risetime/sample interval must be
greater than 1.4 but less than 4. Extra error will occur for two channel measurements due to
channe
l to channel skew. Peak specification is based on statistical accumulation of 1000
waveforms.
Single shot, sample or HiRes, full bandwidth (0.06/sample rate + 2.5 ppm x | reading |)
RMS
±(0.3
0/(sample rate) + (2.5 ppm x | reading
|)) peak
Delta Time Measurement
Accuracy, < 4 GHz models
Average Mode, ≥100 averages, full
bandwidth selected.
± (2.5 ppm x | reading | + 4 ps)
1–40 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
