Specifications (MSO/DPO5000 Series)
This chapter contains specifications for the MSO5000 and DPO5000 series
oscilloscopes. All specifications are guaranteed unless noted as "typical."
Typical spec
ifications are provided for your convenience but are not guaranteed.
Specifications that are marked with the
symbol are checked in Performance
Verification.
All specifications apply to all MSO5000 and DPO5000 models unless noted
otherwise. To meet specifications, two conditions must first be met:
The oscilloscope must have been operating continuously for twenty minutes
within the operating temperature range specified.
You must p erform the Signal Path Compensation (SPC) operation before
evaluating the instrument’s performance to the specifications. (See page 4-26,
Self Test.) If the operating temperature changes by more than 10 °C (18 °F),
perform the SPC operation again.
Table 2-1: Analog channel input and vertical specification
Characteristic Description
Number of input
channels
4 analog channels, digitized simultaneously
Input coupling
DC or AC
Input resistance
selection
1MΩ or 50 Ω
250 kΩ selectable for performance verification.
1MΩ 1MΩ ±1%
50 Ω ±1%
MSO5204,
DPO5204
VSWR ≤1.5:1 from DC to 2 GHz, typical
MSO5104,
DPO5104
VSWR ≤1.5:1 from DC to 1 GHz, typical
MSO5054,
DPO5054
VSWR ≤1.5:1 from DC to 500 MHz, typical
Inp
ut
impedance, DC
coupled
50 Ω
MSO5034,
DPO5034
VSWR ≤1.5:1 from DC to 350 MHz, typical
Input
Capacitance,
1MΩ DC coupled
13 pF ± 2 pF
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 2–1
