Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-5: Digi
tal acquisition specifications (MSO70000/C Series)
Characteristic Description
Minimum signa
l am plitude
300 mV p-p; logic threshold centered in dynamic range of signal;
f ≤1.5 GHz for P6780
f ≤350 MHz for
P6717
Minimum detectable pulse width
(mainframe
and logic probe), typical
<400 ps
Number of pr
obe channels
17
Number of d
igital acquisition channels
16
Digital channel resolution 1 bit, either a 0 or a 1
Logic threshold range
with P6780 probe
with P671
7 probe
-2Vto+5V
-2Vto+4.5V
-1.5 V to +
4.0 V
Logic threshold resolution 5 mV
Logic threshold accuracy (with probe
attache
d), typical
≤3% of threshold setting ±75 mV
Single
acquisition displayed timing
uncertainty between digital channels
with P6780 probe, typical
Withou
t deskew
After deskew
160 ps
80 ps
Number of digital c hannels available
for analog acquisition
4. Any of the 16 acquisition channels + clock qualifier channel can be displayed in place
of any analog channel on the instrument
iCapture bandwidth with general
purpose probe, typical
>300 MHz
iCapture bandwidth with solder-in
differential probe, typical
>2.5 GHz
iCapture rise time with solder-in
differential probe, typical
≤200 ps
Position range of analog iCapture
channels
±5 divisions
iCapture DC analog accuracy
(mainframe and probe)
±(5% of reading +0.2 division)
Gain ranges of analog channels with
probe
250 mV/div, 375 mV/div, 750 mV/div,
1.25 V/div, 1.88 V/div, 3.75 V/div
Digital channel comparison values 0, 1, or don’t care
Word Recognizer trigger functions
Combinational trigger AND, NAND, OR, NOR
Edge qualifi ed combinational
trigger
AND, NAND, OR, NOR qualified on the rising or falling edge, or either edge of CQ, the
qualifying channel
Trigger toggle rate, typical
≥1.5 GHz
Single channel trigger jitter,
typical
5 ps rms for A event edge trigger using low frequency, fast rise time signal
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 1–51
