Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-3: Trigger specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series models (cont.)
Edge trigger sensitivity, not DC
coupled, typical
All sources, positive or negative edge, for vertical scale settings ≥10 mV/div and ≤1V/div
≥ 4 GHz models Trigger Coupling Sensitivity
NOISE REJ 15%FS from DC to 50 MHz
35%FS at 3 GHz
50%FS at 5 GHz
AC Same as DC-coupled limits for frequencies
> 100 Hz, attenuates signals <100 Hz
HF REJ
Same as DC-coupled limits for frequencies
< 20 kHz, attenuates signals > 20 kHz
LF REJ
Same as DC-coupled limits for frequencies
> 200 kHz, attenuates signals < 200 kHz
< 4 GHz models
Trigger coupling
Sensitivity
NOISE REJ 3 the DC-coupled limits
AC Same as DC-coupled limits for frequencies
> 100 Hz, attenuates signals <100 Hz
HF REJ
Same as DC-coupled limits for frequencies
< 20 kHz, attenuates signals > 20 kHz
LF REJ
Same as DC-coupled limits for frequencies
> 200 kHz, attenuates signals < 200 kHz
Trigger level or threshold range
≥ 4 GHz models Trigger Source
Range
Any channel
+120% FS from center of screen
Auxiliary input ±5.0 V
Line 0 V, Not settable
< 4 GHz models Trigger Source Sensitivity
Any channel
±12 divisions from center of screen
Auxiliary input ±5 V
Line Not settable
Trigger level or threshold accuracy,
typical
Edge trigger, DC coupled
Trigger Source
Accuracy
Channel 1, 2, 3, or 4 ± [(2% | trigger level - net offset | ) + (3.5% FS)
+ offset a ccuracy ]
≥ 4 GHz models
Auxiliary
Not specified
Trigger Source
Accuracy
Channel 1, 2, 3, or 4 ± [(2% | deflection | ) + (0.7 divisions ×
volts/division) + offset accuracy]
< 4 GHz models
Auxiliary
Not specified
