Tektronix DPO7000 Series Technical Reference

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-3: Trigger specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series models (cont.)
Trigger position error, typical
Edge trigger, DC coupling, for signals having a slew rate at the trigger point of ≥ 0.5 d ivisions/ns
≥ 4 G Hz models
Acquisition mode Trigger Position Error
Sample, Average ± (1 waveform interval + 50 ps)
< 4 GHz models
Acquisition mode Trigger Position Error
Sample, Average ± (1 waveform interval + 200 ps)
Peak Detect, E nvelope
± (2 waveform intervals + 200 ps)
Time range for time-qualified
triggers
≥ 4 G Hz models S etup/Hold Violation
Setup time
Hold time
Setup + hold time
-100 ns to +100 ns
-1 ns to +100 ns
500 ps minimum
Timeout 400 ps to 1 s
Time qualified window, outside >t
All other types
600 ps to 1 s
300 ps to 1 s
< 4 GHz models
300 ps to 1 s
For Glitch, Width, Time qualified runt, Transition, or Setup/hold violation types
Tim
e-qualified trigger timer
accuracy
Time range Accuracy
Glitch and width triggering (300 ps to 1.0 ns typical)
<300 ns to 1.01 μs
±(3% of setting + 80 ps)
1.02 μsto1s
±(TB accuracy + 100 ns)
Other time-qualified types (300 ps to 1.0 ns typical)
<300 ps to 1.01 μs
±(5% of setting + 200 ps)
≥ 4 G Hz models
1.02 μsto1s
±(TB accuracy + 20 ns)
<1 μs (<2 ns typical) ±(20% of setting + 0.5 ns)< 4 GHz models
1 μsto1s
±(0.01% of setting + 100 ns)
Width and glitch trigger sensitivity, typical
≥ 4 G Hz models 15% x FS from DC to 1 GHz, not violating the minimum timing requirements for each type (for
vertical settings from 10 mV/div to 1 V/div at the input connector)
< 4 GHz models 1.0 division from DC to 1 G Hz (at input connector)
Width and glitch trigger, minimum
timing requirements,
≥ 4 GHz models
For v ertical scale settings 10 mV/div and 1 V/div
Minimum pulse
width
Minimum rearm
time
Setup time
Hold time
Width and glitch types 150 ps 300 ps N.A. N.A.
Logic qualified width and
glitch types
150 ps 300 ps 20 ps 40 ps
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 1–43
