Tektronix DPO7000 Series Technical Reference

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-3: Trigger specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series models (cont.)
Width and glitch trigger, minimum
timing requirements,
<4 GHz models
For vertical scale settings 10 mV/div and 1 V/div
Minimum pulse
width
Minimum rearm
time
Setup time
Hold time
Width type 225 ps 250 ps N.A. N.A.
Logic qualified width type
190 ps 250 ps 40 ps 175 ps
Glitch type
170 ps 250 ps N.A. N.A.
Logic qualified glitch type
100 ps 250 ps 40 ps 60 ps
Runt trigger sensitivity, typical
≥4 GHz models 15% x FS from DC to 1 GHz, not violating the minimum timing requirements for each type (for
vertical settings from 10 mV/div to 1 V/div at the input connector)
<4 GHz models 1.0 division (at input connector)
Runt trigger, minimum timing
requirements,
≥4 GHz models
A runt event occurs at the end of the runt whether or not the runt was time qualified. Logic
qualified runt triggers require that the logic condition be true during the entire duration of the
runt plus some minimum amount of time after the runt event occurred.
Minimum pulse
time
Minimum rearm
time
Setup time
Hold time
Runt type 200 ps 300 ps N.A. N.A.
Logic qualified runt type
200 ps 300 ps 300 ps 300 ps
Time qualified runt type
476 ps 510 ps N.A. N.A.
Time and logic qualified runt
type
520 ps 360 ps 160 ps 105 ps
Runt trigger, minimum timing
requirements,
< 4 G Hz models
A runt event occurs at the end of the runt whether or not the runt was time qualified. Logic
qualified runt triggers require that the logic condition be true during the entire duration of the
runt plus some minimum amount of time after the runt event occurred.
Minimum pulse
time
Minimum rearm
time
Setup time
Hold time
Runt type 225 ps 250 ps N.A. N.A
Time qualified runt type
360 ps 450 ps N.A. N.A.
Logic qualified runt type
Runt width +
150 ps
250 ps 160 ps -16 ps
Time and logic qualified runt
type
Runt width +
330 ps
250 ps 160 ps 175 ps
Pattern and state trigger sensitivity,
DC coupled, typical
≥ 4 GHz models
15% x FS from DC to 1 GHz, not violating the minimum timing requirements for each type (for
vertical settings from 10 mV/div to 1 V/div at input connector)
Logic and state trigger sensitivity,
DC coupled, typical
<4 GHz models
1.0 division from DC to 1 GHz (for vertical settings from 10 mV/div to 1 V/div at input connector)
1–44 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
