Tektronix DPO7000 Series Technical Reference

Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-3: Test record (cont.)
Instrument performance test Minimum Incoming Outgoing Maximum
Ch3 100 mV Vert scale s etting,
0 D iv position setting, 0 V offset
-5 Div position setting, +2.0 V offset
+5 Div position setting, -2.0 V offset
+ 744.80 mV
+ 744.80 mV
+ 744.80 mV
__________
__________
__________
__________
__________
__________
+ 775.20 mV
+ 775.20 mV
+ 775.20 mV
Ch3 200 mV Vert scale s etting,
0 D iv position setting, 0 V offset
-5 Div position setting, +1.25 V offset
+5 Div position setting, -1.25 V offset
+1.49V
+1.49V
+1.49V
__________
__________
__________
__________
__________
__________
+1.55V
+1.55V
+1.55V
Ch3 500 mV Vert scale s etting,
0 D iv position setting, 0 V offset
-5 Div position setting, 0 V offset
+5 Div position setting, 0 V offset
+ 3.724 V
+ 3.724 V
+ 3.724 V
__________
__________
__________
__________
__________
__________
+ 3.876 V
+ 3.876 V
+ 3.876 V
Ch4 10 mV Vert scale setting,
0 D iv position setting, 0 V offset
-5 Div position setting, +0.45 V offset
+5 Div position setting, -0.45 V offset
+ 74.48 mV
+ 74.48 mV
+ 74.48 mV
__________
__________
__________
__________
__________
__________
+ 77.52 mV
+ 77.52 mV
+ 77.52 mV
Ch4 20 mV Vert scale setting,
0 D iv position setting, 0 V offset
-5 Div position setting, +0.4 V offset
+5 Div position setting, -0.4 V offset
+ 148.96 mV
+ 148.96 mV
+ 148.96 mV
__________
__________
__________
__________
__________
__________
+ 155.04 mV
+ 155.04 mV
+ 155.04 mV
Ch4 50 mV Vert scale setting,
0 D iv position setting, 0 V offset
-5 Div position setting, +0.25 V offset
+5 Div position setting, -0.25 V offset
+ 372.40 mV
+ 372.40 mV
+ 372.40 mV
__________
__________
__________
__________
__________
__________
+ 387.60 mV
+ 387.60 mV
+ 387.60 mV
Ch4 100 mV Vert scale s etting,
0 D iv position setting, 0 V offset
-5 Div position setting, +2.0 V offset
+5 Div position setting, -2.0 V offset
+ 744.80 mV
+ 744.80 mV
+ 744.80 mV
__________
__________
__________
__________
__________
__________
+ 775.20 mV
+ 775.20 mV
+ 775.20 mV
Ch4 200 mV Vert scale s etting,
0 D iv position setting, 0 V offset
-5 Div position setting, +1.25 V offset
+5 Div position setting, -1.25 V offset
+1.49V
+1.49V
+1.49V
__________
__________
__________
__________
__________
__________
+1.55V
+1.55V
+1.55V
Ch4 500 mV Vert scale s etting,
0 D iv position setting, 0 V offset
-5 Div position setting, 0 V offset
+5 Div position setting, 0 V offset
+ 3.724 V
+ 3.724 V
+ 3.724 V
__________
__________
__________
__________
__________
__________
+ 3.876 V
+ 3.876 V
+ 3.876 V
Offset accuracy, ≥ 4GHzmodels
Ch1 10 mV Vert scale setting,
-5 Div position setting, +0.45 V offset
5 Div position setting, -0.45 V offset
+ 495.75 mV
- 504.25 mV
__________
__________
__________
__________
+ 504.25 mV
- 495.75 mV
Ch1 20 mV Vert scale setting,
-5 Div position setting, +0.4 V offset
5 Div position setting, -0.4 V offset
+ 494.75 mV
- 505.25 mV
__________
__________
__________
__________
+ 505.25 mV
- 494.75 mV
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 3–31
