Performance Verification (MSO/DPO5000 Series)
Random No ise, Sample Acquisition Mode
Ve rtical sensitivity = 100 mV/div
Performance checks 1 MΩ 50 Ω
Bandwidth Test result (mV) High limit (mV) Test result (m V) High limit (mV)
MSO5204, DPO 5204
Full 8.18 6.15
250 MHz limit 5.12 4.08
Channel 1
20 MHz limit 5.12 4.08
Full 8.18 6.15
250 MHz limit 5.12 4.08
Channel 2
20 MHz limit 5.12 4.08
Full 8.18 6.15
250 MHz limit 5.12 4.08
Channel 3
20 MHz limit 5.12 4.08
Full 8.18 6.15
250 MHz limit 5.12 4.08
Channel 4
20 MHz limit 5.12 4.08
MSO5104, DPO 5104
Full 8.15 6.08
250 MHz limit 5.10 4.05
Channel 1
20 MHz limit 5.10 4.05
Full 8.15 6.08
250 MHz limit 5.10 4.05
Channel 2
20 MHz limit 5.10 4.05
Ful
l
8.1
5
6.0
8
250 MHz limit 5.10 4.05
Channel 3
20 MHz limit 5.10 4.05
Fu
ll
8.
15
6.
08
250 MHz limit 5.10 4.05
Channel 4
20 MHz limit 5.10 4.05
