Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-3: Trigger specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series models (cont.)
Window trigger, minimum timing
requirements,
<4 GHz models
Minimum pulse
width
Minimum rearm
time
Setup time
Hold time
Window 225 ps 300 ps N.A. N.A.
Logic qualified window
190 ps 300 ps -20 ps 0 ps
Transition trigger, minimum timing
requirements, ≥4 GHz models
The transition trigger event occurs at the end of the transition. The logic condition must be
valid at the m oment the transition event occurs minus the setup time plus the hold time. Rearm
time is the time below the lower threshold and the time above the upper threshold. Neither
time can be violated.
Minimum pulse
width
Minimum rearm
time
Setup time
Hold time
Transition type 0 ps 500 ps N.A. N.A.
Logic qualified transition type
0 ps 500 ps 50 ps 50 ps
Transition trigger, minimum timing
requirements, <4 GHz models
The transition trigger event occurs at the end of the transition. The logic condition must be
valid at the m oment the transition event occurs minus the setup time plus the hold time.
Minimum pulse
width
Minimum rearm
time
Setup time
Hold time
Transition type 0 ps 225 ps N.A. N.A.
Logic qualified transition type
330 ps 225 ps 225 ps 175 ps
Transition trigger, delta time range 1 ns to 1 s
Setup/Hold violation trigger, setup
and hold time ranges
Minimum Maximum
Setup time
-100 ns 100 ns
Hold time -1 ns 102 ns
Setup + hold time
500 ps
Setup/hold time violation trigger,
minimum clock pulse widths, typical
Minimum time from active clock edge to
inactive edge
Minimum time from inactive clock edge to
active edge
≥ 4 GHz models
Hold times ≥ 0: Hold time + 550 ps
Hold times <0: Hold time + 1.6 ns
500 ps
500 ps
< 4 GHz models
Hold times ≥ 0: Hold time + 500 ps
Hold times <0: Hold time + 1.5 ns
500 ps
1–46 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
