Tektronix DSA8200 Series

Command Groups
Command
Description
HORizontal:FRAMescan:STATE Sets or returns the FrameScan acquisition
mode on or off
HORizontal:MAGnify<x>?
Returns all Mag<x> timebase settings
HORizontal:MAGnify<x>:POSition Sets or returns the horizontal position for
Mag<x> time
base
HORizontal
:MAGnify<x>:RECordlength
Sets or retu
rns the Mag<x> timebase record
length
HORizontal:MAGnify<x>:REFPoint Sets or returns the Mag<x> timebase
reference point in percent
HORizontal:MAGnify<x>:RESolution?
Returns the Mag<x> timebase acquisition
resolution
HORizontal:MAGnify<x>:SCAle Sets or returns the Mag<x> timebase time
per divi
sion
HORizon
tal:MAGnify<x>:TOFPoint?
Returns
the Mag<x> timebase time of first
point
HORizontal:MAGnify<x>:TOLPoint? Returns the Mag<x> timebase time of last
point
HORizontal:MAGnify<x>:VIEW Sets or returns the Mag<x> timebase view
on or o
ff
HORi
zontal:MAIn?
Retu
rns the time per division of the main
time base
HORizontal:MAIn:POSition Sets or returns the horizontal position for the
main timebase
HORizontal:MAIn:RECordlength Sets or returns the main timebase r ecord
le
ngth
HO
Rizontal:MAIn:REFPoint
Se
ts or returns the main timebase reference
position in percent of record
HORizontal:MAIn:RESolution?
R
eturns the main timebase acquisition
resolution
HORizontal:MAIn:SCAle Sets or returns the main timebase time per
division
HORizontal:MAIn:TOFPoint? Returns the main timebase time of first point
HORizontal:MAIn:TOLPoint? Returns the main timebase time of last point
HORizontal:MATH<x>:MAGnify<x>:
POSition?
Returns the Math<x>"Acquisition" horizontal
position for Mag<x> timebase
HORizontal:MATH<x>:MAGnify<x>:
RECordlength?
Returns the Math<x> Mag<x> timebase
record length
HORizontal:MATH<x>:MAGnify<x>:
RESolution?
Returns the Math<x> Mag<x> timebase
acquisition resolution
HORizontal:MATH<x>:MAGnify<x>:SCAle?
Returns the Math<x> M ag<x> timebase time
per division
HORizontal:MATH<x>:MAGnify<x>:
TOFPoint?
Returns the Math<x> M ag<x> timebase time
of first point
DSA/CSA/TDS8X00/B Series Programmer Manual 2-23
