Tektronix DSA8200 Series

Command Groups
Command
Description
HORizontal:MATH<x>:MAGnify<x>:
TOLPoint?
Returns the Ma
th<x> Mag<x> timebase time
of last point
HORizontal:MATH<x>:MAIn:POSition? Returns the Math<x> horizontal position for
main timebas
e
HORizontal
:MATH<x>:MAIn:RECordlength?
Returns the Math<x> main timebase record
length
HORizontal
:MATH<x>:MAIn:REFPoint?
Returns the Math<x> main timebase
reference p
osition in percent of record
HORizonta
l:MATH<x>:MAIn:RESolution?
Returns the Math<x> main timebase
acquisiti
on resolution
HORizont
al:MATH<x>:MAIn:SCAle?
Returns the Math<x> main timebase time
per divis
ion
HORizont
al:MATH<x>:MAIn:TOFPoint?
Returns t
he Math<x> main timebase time of
first point
HORizontal:MATH<x>:MAIn:TOLPoint? Returns the Math<x> main timebase time of
last point
HORizontal:REF<x>:MAGnify<x>:POSition? Returns the Reference<x> "Acquisition"
horizo
ntal position for Mag<x> timebase
HORiz
ontal:REF<x>:MAGnify<x>:
RECordlength?
Retur
ns the Reference<x> Mag<x> timebase
record length
HORizontal:REF<x>:MAGnify<x>:
RESolution?
Returns the Reference<x> Mag<x> timebase
screen resolution
HORizontal:REF<x>:MAGnify<x>:SCAle? Returns the Reference<x> Mag<x> timebase
time
per division
HOR
izontal:REF<x>:MAGnify<x>:
TOFPoint?
Ret
urns the Reference<x> Mag<x> timebase
time of first point
HORizontal:REF<x>:MAGnify<x>:
TOLPoint?
Returns the Reference<x> Mag<x> timebase
time of last point
HORizontal:REF<x>:MAIn:POSition? Returns the Reference<x> "A cquisition"
ho
rizontal position for main timebase
H
ORizontal:REF<x>:MAIn:RECordlength?
R
eturns the Reference<x> main timebase
record length
HORizontal:REF<x>:MAIn:REFPoint? Returns the Reference<x> main timebase
reference position in percent of record
HORizontal:REF<x>:MAIn:RESolution? Returns the Reference<x> main timebase
screen resolution
HORizontal:REF<x>:MAIn:SCAle? Returns the Reference<x> main timebase
time per division
HORizontal:REF<x>:MAIn:TOFPoint? Returns the Reference<x> main timebase
time of first point
HORizontal:REF<x>:MAIn:TOLPoint? Returns the Reference<x> main timebase
time of last point
HORizontal:TBMode Sets or returns the timebase mode
HORizontal:UNIts Sets or returns the horizontal units
2-24 DSA/CSA/TDS8X00/B Series Programmer Manual
