Phaser 740 and 750 Color Printers
Engine Set Margins Top Margin
Front Margin
Back Left Margin
Paper Path Top Tray
Middle Tray
Multi-purpose Tray
Bottom Tray
Sensors Fr./Rt. Door Top Tray Paper
Left Access Door Top Tray Sw1
Lower Feeder Door Top Tray Sw 2
Fuser Installed Top Tray Sw3
Fuser Roll Installed Middle Tray Paper
Fuser Roll (New/used) Middle Tray Sw1‘
Imaging Unit Installed Middle Tray Sw2
Accumulator Belt Tension Middle Tray Sw3
Charger Unit Installed Bottom Tray Paper
IUT Position Bottom Tray Sw1
Multi-purpose Tray‘ Bottom Tray Sw2
Media
Multi-purpose Tray Pick Bottom Tray Sw3
Position
Registration Roller Black Cart Installed
Fuser Exit Cyan Cart Installed
Paper Exit Magenta Installed
Output Tray Yellow Installed
Auto-duplex Jam
Auto-duplex Gate
Motor Tests Main Motor
Paper Feed Motor
Cartridge Motor
Laser Motor
Lower Feeder Motor
Filter Fan
Power Supply Fan
Fuser Fan
Auto-duplex Unit Fan
Multi-purpose Tray Motor
Black Cam Motor/sensor
Yellow Cam Motor/sensor
Magenta Cam Motor/sensor
Cyan Cam Motor/sensor
Black Cam Motor/sensor
Clutches Black Cartridge Clutch
Yellow Cartridge Clutch
Magenta Cartridge Clutch
Cyan Cartridge Clutch
Registration Clutch
Auto-duplex Unit Clutch
To Next Page
