Engine (cont.) Solenoids Transfer Roller Solenoid
Cleaning Blade Solenoid
Face Up/down Solenoid
Top Pick Solenoid
Middle Pick Solenoid
Bottom Pick Solenoid
Fuser Roll Solenoid
Auto Duplex Unit Bypass Solenoid
Command Engine Main Motor On/off Yellow Roller On/off
Paper Feed Motor On/off Cyan Roller On/off
Cartridge Motor On/off Magent Roller On/off
Laser Motor On/off Registration Clutch
Lower Feeder Motor On/off Paper To Auto
Duplex
Multi-pur Tray Motor On/off Auto-dup Pick Clutch
High Voltage Supply On/off Top Pick Roller
Erase Lamp On/off Middle Pick Roller
All Fans On/off Bottom Pick Roller
Paper To Exit Transfer Roller
Black Cam On/Off Cleaning Blade
Yellow Cam On/Off Face Up/Dn Sole.
Cyan Cam On/Off Fuser Roll Advan Sol
Magenta Cam On/Off Blow New Fuser Roll
Black Roller On/Off Main Motor On
Misc. Tests Erase Lamp
HHS Laser Scanner Seal
Energy Star
Maintenance Clean Accumulator Belt
Clean Top Pick Rollers
Clean Middle Pick Rollers
Clean Bottom Pick Rollers
Clean Multi-purpose Tray Pick Rollers
Engine Status Status 1 Thru 49 Hex Codes
- Engineering Use Only-
General Status Status: <Reports Engine Status>
Top Tray: <Tray Type>
Middle Tray: <Tray Type>
Bottom Tray: <Tray Type>
Engine Control Board ROM Version: <Version>
Fuser Temperature: <Temp Celsius>
Ambient Humidity: <Range Of Relative Humidity>
Ambient Temperature: <Temp Celsius>
Help Turn Help On/off For Each Image Processor And
Engine Menu
To Next Page
