Reference
Options Settings o r subme nu s Comments
Lists the contents of the current USB
flash drive folder and displays the folder
options
Change Folde
r
New Folder
(See page 64, Fi
le Management
Conventions.) (See page 103, File
Utilities for the US B Flash Drive.)
Layout
1
, Portrait,
Landscape
Select portrait or landscape image
layout
Select Folder
Ink Saver
1
,On,Off
Activates
or deactivates Ink Saver mode
Save filename (
such as
TEK0000.TIF)
Saves the
screen image to the
automatically generated file name in the
current USB flash drive folder
1
(See page 90, Print.)
When the print button option is set to Saves Image to File, the oscilloscope saves
screen images to a USB flash drive when you push the Save button. (See page 68,
Saves Image to File.)
Save Setup
The Save Setup action saves the current oscilloscope settings to a file named
TEKnnnn.SET in a specified folder, or in nonvolatile setup memory. A setup fi le
contains an ASCII text string that lists the oscilloscope settings.
Options Settings or submenus Comments
Setup Saves the current oscilloscope settings
to a location in the nonvolatile setup
memory
Save To
File
Saves the current oscilloscope settings
to a file on the USB flash d rive
Setup
1to10
Specifies which nonvolatile setup
memory location to save to
Lists the contents of the current USB
flash drive folder
Change Folder
Select Folder
New Folder
(See page 64, File Management
Conventions.) (See page 103, File
Utilities for the USB Flash Drive.)
Save filename (such as
TEK0000.SET)
Saves the settings to the automatically
generated file name in the current USB
flash drive folder
When the print button o ption is set to Sa ves All to Files, the oscilloscope saves
oscilloscope setup files to a USB flash drive when you push the Save button. (See
page 67, Saves All to Files.)
TDS2000C and TDS1000C-EDU Series Oscilloscope User Manual 93
