Tektronix TDS2000C series User Manual

Reference
Options Settings Comments
Summary of the oscilloscope settingsSystem Status
Misc.
Displays model, m anufacturer serial number, adapters
connected, GPIB setup address, firmware version, and other
information
Printer Set
up
Changes the
printer setup (See page 73.)
GPIB Setup ►
Address
Sets the GPI
B address for the TEK-USB -488 adapter (See
page 72.)
Set Date and Time Sets the date and time (See page 102.)
Options
Error Log
Displays a list of any errors logged and the Power Cycle
count
This log i
s useful if you contact a Te ktronix Service Center
for help.
Do Self Cal Performs a self calibration
File Uti
lities
Displays folder, file, and USB flash drive options (See
page 103.)
Language
English, French, German, Italian,
Spani
sh, Japanese, Portuguese,
Simplified Chinese, Traditional
Chinese, Korean
Selects the display language of the oscilloscope
Key Points
System Status. Selecting System Status from the Utility Menu displays the menus
available for obtaining a list of control settings for each group of oscilloscope
controls.
Push any front-panel menu button to remove the status screen.
Options Comments
Horizontal Lists horizontal parameters
Vertical
Lists vertical parameters of channels
Trigger Lists trigger parameters
Misc
Lists the model of the oscilloscope, the version number of the
software, and the serial number
Lists values of the communications parameters
Setting the Date and Time. You can use the Set Date and Time menu to set the
clock date and time. The oscilloscope displays this information, and also uses it to
time stamp fi les written to a USB flash drive. The oscilloscope contains a built-in
nonreplaceable battery to maintain the clock settings.
The clock does not automatically adjust for seasonal time changes. The calendar
does a djust for Leap years.
102 TDS2000C and TDS1000C-EDU Series Oscilloscope User Manual
