45
Configuration
POSITION NAME SETUP
Name Field
The Name field is used to assign the ADHB-4 unit a user-recognizable name.
This field can contain up to 39 alphanumeric characters.
DESK MIC CONNECTOR SETUP
The Desk Mic Connector Setup section is used to configure the desk mic type and power requirements. A PTT can be
generated from C-Soft or a footswitch for desk mics that require an external PTT.
Mic Connector Drop Down Menu
The Mic Connector drop down menu is used to configure the desk mic connector type. The ADHB-4 supports desk mics with
either an RJ-11 or an XLR connector. Once the type is selected, the Mic type drop down menu options are updated to
correspond with the selected connector type.
Available selections for this field are: RJ11 and XLR.
Mic Type Drop Down Menu
The Mic Type drop down menu is used to configure the desk mic type. The ADHB-4 supports dynamic and electret desk mics.
Dynamic desk mics can come with either an RJ-11 or XLR connector. Electret desk mic are fitted with an RJ-11 type
connector.
Available selections for this field when RJ11 is selected are: Dynamic and Electret.
Available selection for this field when XLR is selected is: Dynamic.
Phantom Power Drop Down Menu
The Phantom Power drop down menu appears when the mic connector type is set to XLR. Use this field to toggle on or off
power supplied to the XLR microphone.
Available selections for this field are: On and Off.
To turn on XLR phantom power, do the following:
1. From the Mic Connector drop down menu, select XLR.
The Phantom Power drop down menu appears. The Mic Type menu defaults to Dynamic.
2. From the Phantom Power drop down menu, select ON.
The red LED on the side of the ADHB-4 indicates power is on.
3. Click Submit.
4. Click the Save Parameters link.
The Save Parameters window appears.
5. Click the Save Parameters button.
The Parameters are saved and the phantom power LED is on.
