System Setup Window
Desk Mic Disable Radio Button
The Desk Mic Disable radio button indicates the desk mic is ignored when a PTT is generated from C-Soft.
FOOTSWITCH PTT SETUP
The Footswitch PTT Setup section is used to set up microphone selection when a PTT is generated from a footswitch
connected to the ADHB-4. Up to four (4) different microphone sources can be set up for a footswitch generated PTT. When
the console operator presses the footswitch, the first available microphone source, that is not disabled or disconnected, is
selected for transmission in the order setup in this section.
The default for these fields are:
Headset Mic #1
RHB 1 #2
RHB 2 #3
Desk Mic #4
EXAMPLE: When the defaults are set, the audio is routed as follows:
If a headset, an RHB 1, an RHB 2 and desk mic are connected, and a PTT is generated from the footswitch,
audio is routed to the headset’s earpiece.
If an RHB 1, an RHB 2, and a desk mic are connected, and a PTT is generated from the footswitch, audio is
routed to RHB 1.
If an RHB 2 and a desk mic are connected, and a PTT is generated from the footswitch, audio is routed to the
RHB 2.
Headset Mic #1–#4 Radio Buttons
The Headset Mic #1–#4 radio buttons indicate the priority for routing audio through the headset when a footswitch PTT is
generated.
Headset Mic Disable Radio Button
The Headset Mic Disable radio button indicates the headset is ignored when a footswitch PTT is generated.
RHB 1 Mic #1–#4 Radio Buttons
The RHB 1 Mic #1–#4 radio buttons indicate the priority for routing audio through the RHB 1 when a footswitch PTT is
generated.
RHB 1 Mic Disable Radio Button
The RHB 1 Mic Disable radio button indicates the RHB 1 is ignored when a footswitch PTT is generated.
RHB 2 Mic #1–#4 Radio Buttons
The RHB 2 Mix #1–#4 radio buttons indicate the priority for routing audio through the RHB 2 when a footswitch PTT is
generated.
RHB 2 Mic Disable Radio Button
The RHB 2 Mic Disable radio button indicates the RHB 2 is ignored when a footswitch PTT is generated.
