52
System Setup Window
Desk Mic PTT No Priority Radio Button
The Desk PTT No Priority radio button indicates audio is routed to the Deck Mic on a, first come first serve basis.
The Desk Mic PTT default is No Priority.
Footswitch PTT #1–#6 Radio Buttons
The Footswitch PTT #1–#6 radio buttons indicate the priority for routing audio when the footswitch is activated.
Footswitch PTT No Priority Radio Button
Footswitch PTT No Priority radio button indicates audio is routed on a, first come first serve basis when the footswitch is
activated
Console Generated PTT #1–#6 Radio Button
The Console Generated PTT #1–#6 radio buttons indicate a console generated PTT is, by default, first priority and audio is
routed to the device configured for the console PTT.
NOTE: This radio button cannot be changed.
SYSTEM PARAMETERS SETUP
LCD Backlight Field
The LCD Backlight field is used to adjust the display’s backlight brightness. The brightness can also be adjusted using the
Backlight softkey on the front panel.
The range for this field is 1 to 10.
The default for this field is 5.
To change the backlight brightness, do the following:
1. From the System Setup window, enter a value from 1 (darkest) to 10 (brightest) in the LCD Backlight field.
2. Click Submit.
The setting takes affect and the display changes accordingly.
Change IP On Display Check Box
The Change IP On Display check box indicates the IP Address can be changed using the softkeys on the front of the unit.
Common Record Unsel Check Box
The Common Record Unsel check box indicates the Unselect audio is included in the common recorder audio.
Submit Button
The Submit button is used to submit changes made to the System Setup window. Once clicked, the new configuration is
temporarily saved.
NOTE: The Save Parameters button must be clicked to permanently save the new configuration to the unit.
