System Status
AUX/RELAY STATUS
AUX 1 Input
The AUX 1 Input field indicates the current state of the AUX 1 input.
Field values can be: Low or High.
AUX 2 Input
The AUX 2 Input field indicates the current state of the AUX 2 input.
Field values can be: Low or High.
Relay 1 Field
The Relay 1 field indicates the current state of the relay 1.
Field values can be: On or Off.
Relay 2 Field
The Relay 2 field indicates the current state of the relay 2.
Field values can be On or Off.
GAINS STATUS
Mic Level Field
The Mic Level field indicates the input gain level for the currently active PTT for any source.
NENA Level Field
The NENA Level field indicates the input gain level for the NENA which is currently off hook.
