Normal Operation Mode
Phantom Power LED Indicator
The Phantom Power LED indicates phantom power is supplied to the desk mic connected to the MIC (XLR) connector on
the left panel of the unit when lit.
Normal Operation Mode
While in Normal Operation mode the ADHB-4 displays icons for speakers, auxiliary devices, relay controlled devices, and
NENA appear across the top of the ADHB-4 display. A volume meter, PTT indicator, time, date, and year occupy the middle
of the display. Softkey labels, up to four (4), appear across the bottom.
USB Indicator Icon
The USB Indicator icon indicates there is a USB connection to a PC running C-Soft.
TABLE 3. USB Icon
Icon Status Description
Confirms the ADHB-4 is connected to a PC.
