LE910Cx Hardware Design Guide
1VV0301298 Rev.40 Page 145 of 149 2023-03-16
Not Subject to NDA
Revision Date Changes
23 2020-04-20 Section 6.2 – Power Consumption updated
22 2020-04-02 Section 7.4 – Diversity ANT PAD changed
21 2020-03-30 Section 2.8.2 – Weight updated
20 2020-01-23 Section 3.1 – WOW pin updated
Section 3.2 – Table updated
Section 3.3 – LGA Pads Layout updated
Section 8.7 – GPIOs table updated
19 2019-11-27 Section 14.4 – Added ANATEL Regulatory notices
18 2019-11-21 Section 8.5.3 – SD/MMC Card interface updated
17 2019-10-29 Section 9.1 – STATUS LED control updated
16 2019-10-22 Section 2.7.2 – Output power updated
15 2019-10-15 Section 3.1 – Warning comment removed
Table 34, 35 – note updated
Table 18 – Updated Idle mode current consumption
Section 14.3 – Added NCC (TW) requirement section
14 2019-09-03
Table 18 – Updated the current consumption of LTE max power
Table 6 – Updated the description of E13 pin-out
14.1 FCC/ISED Regulatory Notices updated for LE910C1/C4-LA
14.1 FCC/ISED Regulatory Notices updated
Table 5 – LTE B2 fixed
Section 2.7.1 – Sensitivity updated
Section 7.5 – Note added for passive or active ANT installation
Table 36 – Network Service Availability Indication updated
13 2019-05-14 Table 1 and 4 LE910C1-xx bis Variants removed
Section 3.2 and 7– Note for C1 bis variants removed
12 2019-04-23 Table 1, 4 – Added variants
Table 19,21 – Added comment
11 2019-03-22 Section 10.7.1 – Warning comment added
10 2019-03-13 Section 2.8.1 – Note added for C1-SV variant
Section 3.1 – Updated E13 Pin-out
Section 3.3 – Updated figure 2. LGA Pads Layout
Added Fast Power Down Section 5.5
Table 18 – Updated Idle mode current consumption
