OMNIA MPX NODE MANUAL
Encoder GPIO Functions
Encoder GPO Latch Func-
tions
Encoder GPI Latch Functions
Net1 Status
Up (high)
Down (low)
µMPX Enccoder:
Start (high)
Stop (low)
Net2 Status
Up (high)
Down (low)
Input audio Clipping
Encoder GPO Pulse Functions Encoder GPI Pulse Functions
Network1 up Start µMPX Encoder
Network1 down Stop µMPX Enccoder
Network2 up Restart µMPX Encoder
Network2 down Reboot MPX Node
Input audio Clipping
Decoder GPIO Functions
Decoder GPO Latch Func-
tions
Decoder GPI Latch Functions
Stream Received:
Yes (high)
No (low)
Active Stream Port:
Main (high)
Alternate (low)
Stream Playing:
Yes (high)
No (low)
µMPX Decoder:
Start (high)
Stop (low)
Net1 Status
Up (high)
Down (low)
Test Tone:
Stop (High)
Play (low)
Net2 Status
Up (high)
Down (low)
