ACT6000 User Guide – January 2021 Page 6 of 52
● Automatic measurements on pre-configured transmissive masks (ETSI or ANSI):
▪ Single-End and End-to-End automatic test sequences for copper pair and
POTS link qualification and certification by the ASW-1/II (optional software).
3.3. Measure Saving & Export
All the results of the performed measurements can be saved on internal memory
exportable to the external USB Pen-Drive or PC (by the specific PC Utility) in .CSV *
format.
It is also possible to export the screenshot in .BMP format.
The above mentioned PC Utility (Windows compatible) is free for download on
https://tescomusa.com/pages/act6000-applications and useful to direct software uploading,
editing and direct uploading of Data Cables and Threshold Limits, and the downloading of
the CSV files saved on internal memory.
● Advanced Software 1/II (optional)
The adoption of the ASW-1/II adds some automatic measurements according to the pre-
configured standard ETIS and ANSI masks on which are pointed-out the threshold limits
and “Pass” / “Fail” indications:
- Automatic Single-End Sequence to perform the copper lines pre-qualification, with
length within 50 and 4,500 meters.
- Manual Single-End Measurements shown in real-time.
- Automatic End-to-End Sequence to perform the qualification also on very long lines or
voice/data cannels, using a couple of ACT6000s.
- Automatic Telephone End-to-End Sequence to perform the POTS link qualification
using a couple of ACT6000s.
3.4. Power Supply and Battery charge
When using the instrument without external supply, it is possible to check continuously the
state of charge of the batteries, thanks to the icon.
An acoustic beep indicates the low batteries charge.
The ACT6000 is fitted with a polarized socket “SUPPLY” for the connection to the AC
Power Supply Adapter for battery charge.
When the right DC voltage is supplied to the above mentioned socket, the charging status
is shown by the led on top panel:
Green led “Ready” or “prompt to charge” and yellow led “Charge” or
“batteries on charge”, at the final phase of charge, orange led “T.O.C.” or
“Top of Charge”. The lighting of the red led “Fault” means a temperature alarm of the
batteries or related charger circuits.
Note* The CSV files are compatible with the Windows Excel application to visualize and to edit
graphics and data base.
