HYDRAULIC PULLER-TENSIONER PT1250
Manual: MI-PT1250-050-01-IT Date: 06.11.2017 Author: AT Page: 41 of 69
Selecting the button on the
bottom left, they activate the
selected commands.
This will make it possible:
1- Increase the pressure in the circuit reel elevators;
2- Decrease the pressure in the circuit reel elevators;
3- Increase the value of shooting;
4- Decrease the value of shooting;
5- Release circuit with bull-wheels (bull-wheels virtual joystick);
6- Recover with bull-wheels circuit (bull-wheels virtual joystick);
7- Display the Virtual bull-wheels joystick position;
ATTENTION
Disconnect the radio control to anything bull-wheels rotation speed (stopped
machine).
ATTENTION
Taking command from the screen to the radio control, the stringing parameters are
not transferred. The machine is reset by taking the parameters set on the radio
control.
1
3
5
2
4
6
7
