TESTO 300 LL - Connect probes

7 First steps
17
7.6
Connect probes
Flue gas probes

Instrument is turned on.
1
Insert the connector plug into the flue
gas socket and lock it in place by
turning it slightly clockwise (bayonet
lock).
There must be no more than one extension line (0554 1201) between
measuring instrument and flue gas probe.
Temperature adapter

Instrument is turned on.
1
Insert the connector plug of the
probe into the probe socket.

System recognizes the probe (info is displayed).
When an external “ext.” probe is used, the display will show “ext.”.
