10 Maintenance
66
Place the instrument on its front again.
Remove the remaining four screws on the back of the instrument.
Lift off the back of the instrument.
Assembly
Perform in reverse order to assemble. Please note:
- Lay hoses and lines in the guides intended for this purpose.
- Make sure that hoses and lines do not get jammed.
Replace sensors
A slot bridge (0192 1552) must be inserted in slots which are not
equipped with a sensor. Used sensors must be disposed of according
to local regulations!
Available slots:
1
NO sensor type 3
O2 sensor type
When retrofitting a sensor, the associated measurement parameter/unit
must be enabled in the reading display.
