TESTO Saveris T3 Commissioning Instructions

8 Technical data
113
Feature Value
Dimensions
T1: 33 x 9 x 74 mm
T2, T3, T4: 44 x 12 x 97 mm
Weight T1: 25 g
T2, T3, T4: 45 g
Directives, standards,
certificates
EN 12830, HACCP-certified, temperature
calibration certificate traceable according to
ISO 17025, RTCA/DO-160G
Probe type T1, T2, T3: internal NTC temperature sensor
T4: internal PT1000 temperature sensor
8.6 testo Saveris router
Feature Value
Housing dimensions (W x H
x D)
80 x 100 x 38 mm
Antenna length
81 mm
Weight
Approx. 180 g
Power supply 6.3 V DC mains unit;
alternatively via 24 V AC/DC plug-in/screw
terminals,
power consumption < 5 W
Housing material
Plastic
Protection class
IP54
Operating temperature
-20 to +50°C
Storage temperature
-40 to +60°C
Interfaces
Radio
Number of radio probes
Max. 5; in a router cascade of max. 3 routers
Wall bracket
Included
