TESTO Saveris T3 Commissioning Instructions

8 Technical data
115
Feature Value
Power supply
6.3 V DC mains unit;
alternatively via 24 V AC/DC plug-in/screw
terminals,
PoE, power consumption < 2 W
Housing material
Plastic
Protection class
IP54
Operating temperature
-20 to +50°C
Storage temperature
-40 to +60°C
Interfaces
Radio, Ethernet
Number of radio probes
Max. 100
Radio frequency
868 MHz
Wall bracket
Included
8.9 BT Gateway for testo 182
Feature Value
Housing material
PC ABS
Dimensions (W x H x D)
Approx. 95 x 68 x 48 mm
Weight
90 g
Protection class
IP20
Storage temperature
-20°C to +70°C
Operating temperature
0°C to +50°C
Humidity
0 to 95% (non-condensing)
Power supply
Mains adapter 5 VDC (USB) / PoE
Interfaces
LAN / USB
Memory capacity
1500 data records (BTLE data logger)
Recording interval
The gateway constantly searches for data
loggers (BTLE)
