TESTO Saveris T3 Commissioning Instructions

6 Commissioning
57

The welcome dialogue for the startup
wizard is displayed.
2
Click on [Next >].

The System status dialogue is displayed with the General tab.
3
Switch to the Integrate router tab.
The direct connection type means that the data logger is directly
registered on the Saveris base or a Saveris converter.
4
Click in the Connection type cell of the data logger which needs to be
assigned to a Saveris router.

The cell is shown as a selection list.
5
Use the button to open the selection list and select the Saveris router
which the data logger needs to be assigned to.
5.1
Perform steps 4 to 5 for all other data loggers with measurement data
that need to be transmitted to the Saveris base via a Saveris router.
6
Position the data logger and Saveris router at their mounting locations
to check the radio links.
