TESTO Saveris T3 Commissioning Instructions

6 Commissioning
69
5
Push the radio data logger
onto the wall bracket
until it clicks into place.
The Saveris T1/T1D/T2/T2D/Pt/PtD/H4D radioi data loggers can be
protected against impact or high-pressure cleaning with the Saveris
protective housing (order no. 0572 0200).
The two halves of the protective housing are force fitted together, even
if the screw connection has already been loosened. To loosen them,
carefully use a screwdriver on the external screws. Do not damage the
surrounding seal in the process.
When assembling the Saveris protective housing, the screws must be
tightened and the unassigned connections must be sealed with the
supplied plugs to ensure IP protection to IP 69 K.
