B.2 MSP-FET430UIF Revision History
MSP-FET430UIF Revision History
Revision 1.3
Initial released hardware version
Assembly change on 1.3 (May 2005)
R29, R51, R42, R21, R22, R74: value changed from 330R to 100R
Changes 1.3 to 1.4 (Aug 2005)
J5: VBUS and RESET additionally connected
R29, R51, R42, R21, R22, R74: value changed from 330R to 100R
U1, U7: F1612 can reset TUSB3410; R44 = 0R added
TARGET-CON: pins 6, 10, 12, 13, 14 disconnected from GND
Firmware-upgrade option through BSL: R49, R52, R53, R54 added; R49, R52 are currently DNP
Pullups on TCK and TMS: R78, R79 added
U2: Changed from SN75LVC1G125DBV to SN75LVC1G07DBV
Assembly change on 1.4 (January 2006)
R62: not populated
Note: Using a locally powered target board with hardware revision 1.4
Using an MSP-FET430UIF interface hardware revision 1.4 with populated R62 in
conjunction with a locally powered target board is not possible. In this case, the target
device RESET signal is pulled down by the FET tool. It is recommended to remove R62
to eliminate this restriction. This component is located close to the 14-pin connector on
the MSP-FET430UIF PCB. See Figure B-25 for the exact location.
SLAU138F June 2004 Revised March 2007 Hardware 63
