Appendix D
SLAU138F – June 2004 – Revised March 2007
80-Pin MSP430F44x and MSP430F43x Device Emulation
80-pin MSP430F44x and MSP430F43x devices can be emulated by the 100-pin
MSP430F449 device. Table D-1 lists where the pin signals of an 80-pin device appear
on the pins of an MSP-TS430PZ100 target socket module.
Note: The MSP-TS430PZ100 must be modified as indicated. See
Section C.1.8 , Emulator → Advanced → Emulation Mode to enable
the emulation mode.
Topic .................................................................................................. Page
D.1 F4xx/80-Pin Signal Mapping ....................................................... 70
SLAU138F – June 2004 – Revised March 2007 80-Pin MSP430F44x and MSP430F43x Device Emulation 69
Submit Documentation Feedback
To Next Page
