F4xx/80-Pin Signal Mapping
Table D-1. F4xx/80-pin Signal Mapping (continued)
Connection Required
MSP430-TS430PZ100
F4xx/80-pin Signal F4xx/80-pin Pin Number Between Indicated Pins of
Pin Number
MSP430-TS430PZ100 Socket
P3.0/STE0/S31 43 43 43-71
COM0 44 52
(1)
P5.2/COM1 45 53
P5.3/COM2 46 54
P5.4/COM3 47 55
R03 48 56
P5.5/R13 49 57
P5.6/R23 50 58
P5.7/R33 51 59
DVcc2 52 60
DVss2 53 61
P2.5/URXD0 54 74
(1)
P2.4/UTXD0 55 75
P2.3.TB2 56 76
P2.2/TB1 57 77
P2.1/TB0 58 78
P2.0/TA2 59 79
P1.7/CA1 60 80
P1.6/CA0 61 81
P1.5/TACLK/ACLK 62 82
P1.4/TBCLK/SMCLK 63 83
P1.3/TBOUTH/SVSOUT 64 84
P1.2/TA1 65 85
P1.1/TA0/MCLK 66 86
P1.0/TA0 67 87
XT2OUT 68 88
XT2IN 69 89
TDO/TDI 70 90
TDI 71 91
TMS 72 92
TCK 73 93
RST/NMI 74 94
P6.0/A0 75 95
P6.1/A1 76 96
P6.2/A2 77 97
Avss 78 98
DVss1 79 99
Avcc 80 100
(1)
Note discontinuity of pin numbering sequence
SLAU138F – June 2004 – Revised March 2007 80-Pin MSP430F44x and MSP430F43x Device Emulation 71
Submit Documentation Feedback
