102
Share Folder
From the Storage menu, choose Share Folders, and the Shared Folder screen
appears. This screen allows you to create and configure folders on the Thecus IP
storage volume.
Adding Folders
On the Folder screen, press the Add button and the Add Folder screen appears.
This screen allows you to add a folder. After entering the information, press Apply
to create new folder.
Add Folder
Item
Description
RAID ID
RAID volume where the new folder will reside.
Folder Name
Enter the name of the folder.
Description
Provide a description the folder.
Browseable
Enable or disable users from browsing the folder contents. If Yes
is selected, then the share folder will be browseable.
Public
Admit or deny public access to this folder. If Yes is selected, then
users do not need to have access permission to write to this
folder. When accessing a public folder via FTP, the behavior is
similar to anonymous FTP. Anonymous users can
upload/download a file to the folder, but they cannot delete a file
from the folder.
Apply
Press Apply to create the folder.
