Thecus N7510 User Manual

76
Jumbo Frame Support
Enable or disable Jumbo Frame Support of the associated interface on your
Thecus IP storage.
Link Type
Select from drop down list for desired mode.
IPv4/IPv6
Click to enable IPv4/IPv6 for TCP/IP. The default is IPv4 enabled.
Mode
It has to be a static IP with the link aggregation being used.
IP
IP address of link aggregation.
Netmask/Prefix Length
Input netmask for IPv4 and Prefix length for IPv6.
Gateway
Gateway for associated link aggregation
Default gateway
It can be chosen from the drop down list of default gateway being used for
the Thecus IP storage.
Now under the networking, a “Link1” tab will appear from the network title bar.
To modify or delete LINK1, go to Link Aggregation setting page. Click on
to modify the settings or click on to delete this link aggregation. If any
ports are still available, additional link aggregation links can be created by clicking
.
Additional LAN
Other than on-board LAN port, Thecus IP storage supports additional NIC to be
added in its available PCI-e slot. For the details of additional NIC support list please
visit Thecus website.
http://www.thecus.com/sp_comlist.php
Once the additional NIC is installed into Thecus IP storage, the “Additional LANx”
will appear under the “Networking” category. Click the associated NIC to setup the
details. The screen shot below shows an example of an Intel PRO/1000 PT Quad
port installed thru a PCI-e slot in the Thecus IP storage.

Thecus N7510 Specifications

General

RAID levels	0, 1, 5, 6, 10, 50, JBOD
Hot-swap drive bays	Yes
Storage drive capacity	- GB
Supported file systems	ext3, ext4, XFS
Storage drive interface	Serial ATA
Total installed storage capacity	- TB
Number of storage drives installed	-
Number of storage drives supported	7
Internal memory	2 GB
Internal memory type	DDR3
Processor family	Intel Atom®
Number of processors installed	1
Data link protocols	TCP/IP/AppleTalk
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	SMB/CIFS, HTTP/HTTPS, FTP, NFS v4, AFP
I/O ports	1 x mic 1 x line-in 1 x audio out
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista/ 7 UNIX/Linux Mac OS X
Security algorithms	256-bit AES
Cables included	AC
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	2
Bundled software	Acronis True Image Thecus Backup Utility
Display type	LCD
Product color	Black, Silver
Power supply unit (PSU) capacity	300 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Sustainability certificates	RoHS
Certification	CE/FCC/C-Tick/VCCI/BSMI VMware, Citrix, WEEE

Weight and Dimensions

Depth	270 mm
Width	210 mm
Height	320 mm
Weight	8400 g
