50
Chapter 4: System Administration
Overview
The Thecus IP storage provides an easily accessible Web Administration
Interface. With it, you can configure and monitor the Thecus IP storage anywhere
on the network.
Web Administration Interface
Make sure your network is connected to the Internet. To access Thecus IP storage
Web Administration Interface:
1. Type the Thecus IP storage IP address into your browser. (Default IP
address is http://192.168.1.100)
2. Login to the system using the administrator user name and password. The
factory defaults are:
User Name: admin
Password: admin
If you changed your password in the setup wizard, use the new password.
Once you are logged in as an administrator, the disclaimer page will appear as
below. Please click the check box if you do not want to have this page displayed
during the next login.
NOTE
Your computer’s network IP address must be on the same subnet as the Thecus
IP storage. If the Thecus IP storage has default IP address of 192.168.1.100,
your managing PC IP address must be 192.168.1.x, where x is a number
between 1 and 254, but not 100.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Thecus N7510 and is the answer not in the manual?

Thecus N7510 Specifications

General IconGeneral
RAID levels0, 1, 5, 6, 10, 50, JBOD
Hot-swap drive baysYes
Storage drive capacity- GB
Supported file systemsext3, ext4, XFS
Storage drive interfaceSerial ATA
Total installed storage capacity- TB
Number of storage drives installed-
Number of storage drives supported7
Internal memory2 GB
Internal memory typeDDR3
Processor familyIntel Atom®
Number of processors installed1
Data link protocolsTCP/IP/AppleTalk
Ethernet LAN data rates10, 100, 1000 Mbit/s
Maximum data transfer rate1000 Mbit/s
Supported network protocolsSMB/CIFS, HTTP/HTTPS, FTP, NFS v4, AFP
I/O ports1 x mic 1 x line-in 1 x audio out
Networking featuresGigabit Ethernet
Compatible operating systemsWindows 2000/XP/2003/Vista/ 7 UNIX/Linux Mac OS X
Security algorithms256-bit AES
Cables includedAC
USB 2.0 ports quantity4
Ethernet LAN (RJ-45) ports2
Bundled softwareAcronis True Image Thecus Backup Utility
Display typeLCD
Product colorBlack, Silver
Power supply unit (PSU) capacity300 W
Operating temperature (T-T)5 - 40 °C
Operating relative humidity (H-H)0 - 80 %
Sustainability certificatesRoHS
CertificationCE/FCC/C-Tick/VCCI/BSMI VMware, Citrix, WEEE
Weight and Dimensions IconWeight and Dimensions
Depth270 mm
Width210 mm
Height320 mm
Weight8400 g
